BOP Control System

The BOP control system is an important equipment for controlling the bop and hydraulic gate valve. It is an indispensable device in drilling andwell workover treatment. Cangzhou Fengliang Petroleum Machinery Co.,Ltd is well control equipment manufacturing center of CNPC.

We have the production capacity of FKQ, FKDQ, FKD and other series of bop control system. Rongsheng has obtained the National Industrial Production License, API 16D, API Q1 and ISO9001 quality management system certification and other qualifications. Rongsheng is the supplier of China National Petroleum Corporation, Sinopec and CNOOC.

Type Illustration of BOP Control System:

 FKQ Series BOP Control System: Pneumatic Controlled

FKDQ Series BOP Control System: Electric-Pneumatic Controlled, PLC based control, Driller ' s Panel (touch screen or electric button), Wireless remote control function can be selected FKD Series BOP Control System: Electric Controlled, Rongsheng patent products, Electromagnet driven, PLC based control, Driller ' s Panel (touch screen or electric button), Wireless remote control function can be selected

Note:  Q: The FKQ series uses hose bundle to connect the driller ' s panel with the remote control panel,the driller operating element is pneumatic rotary valves, remote control panel uses cylinder to drive the 4-way 3-position valve,this series can choose pneumatic-manual or pneumatic Motor driven pressure regulating valves.

DQ: The FKDQ series uses signal cableto connect the driller ' s panel with the remote control panel, the driller operating element is touch screen or electric button, remote control panel uses cylinder to drive the 4-way 3-position valve, with pneumatic Motor driven pressure regulating valves.

D: The FKD series uses signal cableto connect the driller ' s panel with the remote control panel, the driller operating element is touch screen or electric button, remote control panel uses electromagnet to drive the 4-way 3-position valve, with electromotor driven pressure regulating valves. If the customer want to order an API Spec. 16D control system, and you need to mark the API monogram on it, you need to obtain a form named “configuration and parameters of the bop stacks for order an API Spec. 16D control system (land and surface)” from Cangzhou Fengliang Petroleum Machinery Co.,Ltd  sales department. After filling in the detailed technical parameters, the Cangzhou Fengliang Petroleum Machinery Co.,Ltd  technical department will carry out the selection calculation.

The optional device: All series can choose BOP heating units, to heating bop in extremely cold environment, enable the bop to function normally (the BOP should have heating function). FKDQ & FKD series can choose wireless remote control function.
