Top Drive System is a new-style drilling system, which is used to instead of the rotary table. It is integrated with mechanical, electrical and hydraulic technology and has advanced automation level. It’s called a great revolution in drilling equipment and also gives the direction for drilling equipment development in 21st century. Top Drive System has been the standard equipment in the international drilling industry and is suitable to be used in cluster directional well, high-inclination well and horizontal well, ESPecially deep well and ultra deep well.
Features:
Control technology is with the mechanical, electronic and hydraulic integration; output parameters of frequency converter are matched with the characteristics of the Motor; PLC programme can be designed according to the requirement of the customer. It has functions of monitoring, alarming, self-diagnosis, protection and interlocking, which conform to drilling condition.
Rotating head adopts two ducts to supply oil to tilt hydro cylinder, so link can incline forward and swing backward; as each duck is sealed doubly, the leakage is reduced greatly and the reliability of the equipment is improved; the rotating head can rotate with drilling tools while tripping, so the settlement of the accident is easier.
It has double load channels. The bearing of gearbox bears the weight during drilling and the bearing of rotating head bears the weight during tripping, therefore, the service life of bearings and main shaft will be prolonged and anti-vertical vibration of drilling string will be improved.
L-type back up tong applied is easy for replacing tong head, tong dies, upper & lower IBOP and saver sub.
The hydraulic pump can be turned off while drilling and directional well drilling, thus the service life of the pump will be prolonged. In case that hydraulic system breaks down, drilling and reaming can be continued.
Integrated hydraulic system and oil tank are placed on the body of the top drive; the system sends out low heat, which is convenient for installation.
Scientific design, compact structure and reasonable arrangement make onsite maintenance, parts replacement, assemble and disassemble much more easily.
Top drive operating temperature -45°C, storage temperature -60°C.
